Factory Lead Time

12 Weeks

Mount

Bulkhead, Panel, Rear Side Nut

Mounting Type

Panel Mount

Mounting Feature

Bulkhead - Rear Side Nut

Operating Temperature

-40°C~100°C

Packaging

Bulk

Series

Amphe - PPM® Sealed

Published

2006

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

Termination

Solder Cup

ECCN Code

EAR99

Connector Type

Receptacle, Female Sockets

Number of Positions

5

Color

Silver

Applications

Communication Systems, Instrumentation, Medical, Testing Equipment

Gender

Receptacle

Fastening Type

Push-Pull

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

YES

Filter Feature

NO

Mixed Contacts

NO

Option

GENERAL PURPOSE

Current Rating (Amps)

13A

Total Number of Contacts

5

Ingress Protection

IP67 - Dust Tight, Waterproof

Reach Compliance Code

unknown

Current Rating

3A

Shell Finish

Nickel

Shell Size - Insert

C

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Empty Shell

NO

Backshell Type

SOLID

Coupling Type

SNAP

Features

Backshell

Material Flammability Rating

UL94 V-0

RoHS Status

RoHS Compliant

Lead Free

Lead Free

Ratings

Dust Tight, IP67, Waterproof
